B.O.S.S.

Manufactured offsite, the prefabricated components are delivered to site complete with brick slips adhesively bonded and mechanically fixed to the stainless steel carrier unit.

B.O.S.S. is available in many brick bond patterns including:

• Header Bond
  This solution is used to create header bond pattern details at openings. The header bond detail on the B.O.S.S. unit differentiates face finish brickwork from the brickwork on the main façade.
• Stretcher Bond
  This solution is used to create deep soffits providing continuity with the brickwork on the main façade. Adjacent soffit units are designed to interlock, blending seamlessly together once the brickwork is pointed.
• Half Lap Bond
  This solution is used to create half lap bond details at openings. The half lap bond detail on the B.O.S.S. differentiates the face finish brickwork from the brickwork on the main façade.
• Soldier Bond
  This solution is used to create soldier bond details at openings. The soldier bond detail on the B.O.S.S. unit differentiates the face finish brickwork from the brickwork on the main façade.

Bespoke solutions including other brick arrangements can be designed to suit specific project requirements.

B.O.S.S. is a two-part system designed to be fitted to the underside of IG’s Welded Masonry Support (WMS) and steel lintels and offers adjustability on all three planes.

Horizontal adjustment
Horizontal adjustment is achieved by utilizing the channel in the IG Brick On Soffit System (B.O.S.S.) unit. The unit can be moved left or right on the pre-installed IG WMS.

Vertical adjustment
Vertical adjustment can be achieved by inserting stainless steel packers between the Welded Masonry Support or steel lintel system and the B.O.S.S. unit under shelf angle.

Lateral adjustment (Z)
Lateral adjustment is achieved by utilizing the slotted hole located on the shelf angle. Once alignment and levels are correct, bolts should be torqued to 20 Nm (14.75 lb/ft).
